AVENTOS HF lift mechanism set

chevron_left Back
AVENTOS HF lift mechanism set
AVENTOS HF lift mechanism set
Ident no: 09007822
Part no.: 20F2800.05KRAFTSP S2 ZN
Box qty: 1 pc
  • type: lift mechanism set
  • power factor: 9000–17250 (with 2 pcs.)
  • motion technology: integrated BLUMOTION / suitable for SERVO-DRIVE
  • fixing method on the cabinet: with screws
AVENTOS HF bi-fold lift system, lift mechanism (Set), PF=9000-17250 (with 2 pieces), for screwing on, suitable for SERVO-DRIVE, Zinc plated
Ident no: 09007822 Part no.: 20F2800.05KRAFTSP S2 ZN Box qty: 1 pc
  • type: lift mechanism set
  • power factor: 9000–17250 (with 2 pcs.)
  • motion technology: integrated BLUMOTION / suitable for SERVO-DRIVE
  • fixing method on the cabinet: with screws
error_outline

Please log in to see prices and availability.
  • info Product information
  • description Technical data
  • CAD/CAM data
  • handyman Assembly instructions
info Product information expand_more

Product information

Der Kraftspeicher sorgt für leichtes und komfortables Öffnen von Klappen. Dieser dient dazu, das Gewicht der Front auszugleichen und diese in jeder gewünschten Position zu halten. Es handelt sich um ein mechanisches Bauteil, das an der Korpusseite befestigt wird.
description Technical data expand_more

Technical data

type
lift mechanism set
lift system
AVENTOS HF
suitable for lift system type
HF
power factor
9000–17250 (with 2 pcs.)
motion technology
integrated BLUMOTION / suitable for SERVO-DRIVE
