AVENTOS HL top fixing
AVENTOS HL top fixing
Ident no: 02272763
Part no.: 22Q080Z VBST+ZT V1 TGR
Box qty: 1 pc
AVENTOS HL top lift up, connecting piece for cross stabiliser, round, length: 80 mm, deep grey
Ident no: 02272763 Part no.: 22Q080Z VBST+ZT V1 TGR Box qty: 1 pc
error_outline

Please log in to see prices and availability.

  • info Product information
  • description Technical data
  • CAD/CAM data
info Product information expand_more

Product information

The connecting piece is used to connect two cross stabilisers. Use of the connecting piece is only recommended from an internal cabinet width of 1190 mm or from a cabinet width of 1228 mm.
description Technical data expand_more

Technical data

type
fixing
colour/surface
blank
diameter
20 mm
lift system
AVENTOS HL top
material
nylon/zinc
