AVENTOS HS connecting piece

chevron_left Back
AVENTOS HS connecting piece
AVENTOS HS connecting piece
Ident no: 04767297
Part no.: 20Q153ZN VBST+ZT V1 EV1
Box qty: 1 pc
AVENTOS HS up & over lift system, connecting piece for cross stabiliser pre-mounted, round, E6/Ev1 natural
Ident no: 04767297 Part no.: 20Q153ZN VBST+ZT V1 EV1 Box qty: 1 pc
error_outline

Please log in to see prices and availability.
  • info Product information
  • description Technical data
  • CAD/CAM data
info Product information expand_more

Product information

Das Verbindungsstück dient dem Verbinden zweier Querstabilisierungen. Das Verbindungsstück wird ab einer lichten Korpusweite von ≧ 1190 mm eingesetzt.
description Technical data expand_more

Technical data

type
connecting piece
colour/surface
E6/EV1 natural
diameter
16 mm
lift system
AVENTOS HS
scope of delivery
1x connecting piece for lift systems, 2x cover cap for connecting piece, 1x fixing
