Drilling head rotating sense of spindle 4 right, 5 left

chevron_left Back
Drilling head rotating sense of spindle 4 right, 5 left
Drilling head rotating sense of spindle 4 right, 5 left
Ident no.: 05440963
Part no.: MZK.190S LOCHG-B R204
Box qty: 1 pc
Drilling head for MINIPRESS M, for MINIPRESS P, number of spindles 9, quick connect chuck, system drilling, mini hinge (except with boss 80.014-R1), R2004 pure orange
Ident no.: 05440963 Part no.: MZK.190S LOCHG-B R204 Box qty: 1 pc
error_outline

Please log in to see prices and availability.
  • build Technical data
  • CAD/CAM data
build Technical data expand_more

Technical data

type
drilling head
colour/surface
RAL 2004 pure orange
number of spindles
9
rotating sense of spindle
4 right, 5 left
scope of delivery
9x Operating instructions, 1x drilling head
