LEGRABOX front piece height C

chevron_left Back
LEGRABOX front piece height C
LEGRABOX front piece height C
Ident no: 01631940
Part no.: ZV7.1043C01VORD-ST 12CS-M
Box qty: 12 pcs
  • type: front piece
  • height: C
  • colour/surface: carbon black matt
  • height: 98.35 mm
  • length: 1043.2 mm
  • suitable for front design: gallery front / closed front piece
LEGRABOX Front section, for inner drawer and inner pull-out with cross gallery, CW=1200 mm, for cutting to size, carbon black matt
Ident no: 01631940 Part no.: ZV7.1043C01VORD-ST 12CS-M Box qty: 12 pcs
  • type: front piece
  • height: C
  • colour/surface: carbon black matt
  • height: 98.35 mm
  • length: 1043.2 mm
  • suitable for front design: gallery front / closed front piece
error_outline

Please log in to see prices and availability.

  • info Product information
  • description Technical data
  • CAD/CAM data
info Product information expand_more

Product information

The base element of the front of inner pull-outs is the front piece. This is suitable for use in a range of different combinations, for example with a glass design element or a gallery.
description Technical data expand_more

Technical data

type
front piece
suitable for design line
free / pure
height
C
internal cabinet width
0-1170.2 mm
material
aluminium
